SHARK & JANGLI GROUP COMPANY
Product Details
Place of Origin: China
Brand Name: shark
Certification: CE
Model Number: BPG-200
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 5300-17000 USD
Packaging Details: wooden case
Delivery Time: 9 weeks
Payment Terms: T/T,L/C
Supply Ability: 100 per year
Products: |
Desiccant Inserting Machine |
Model: |
BPG-200 |
Max.speed: |
130 Bottles/min |
Net Weight: |
280kg |
Voltage: |
220v |
Frequency: |
50Hz |
Total Power: |
0.5kw |
Products: |
Desiccant Inserting Machine |
Model: |
BPG-200 |
Max.speed: |
130 Bottles/min |
Net Weight: |
280kg |
Voltage: |
220v |
Frequency: |
50Hz |
Total Power: |
0.5kw |
PharmaDri Desiccant Filling Automation System
| projects | parameters |
| max.speed | 130 bottles/min |
| bottle volume(ml) | within 350ml |
| desiccant roller specificatiion(mm) | Extermal diameter within 300mm,inner diameter is 75mm,the thickness of desiccant between 90mm and 140mm. |
| dessicant bag specification | The width of desiccant bag can't wider than 35mm,the length of desiccant bag depends on bottle and packing amount |
| voltage/frequency(V/Hz) | 220/50 |
| total power(kw) | 0.5 |
| air consumption(m³/h) | 0.1 |
| net weight (kg) | 280 |
1.Core Purpose
This specialized machinery automates precise desiccant insertion in pharmaceutical packaging, controlling moisture to preserve medication integrity. It replaces error-prone manual insertion, extending shelf life and enhancing production efficiency across pharmaceutical operations.
2.Key Functions
Desiccant Handling: Sorts and dispenses pre-packaged silica gel sachets or canisters, with precision picking from rolls for bottle/carton insertion.
Calibrated Dosing: Advanced mechanisms deliver custom desiccant quantities based on bottle size, moisture sensitivity, and storage requirements.
Line Synchronization: Seamlessly integrates with unscramblers, fillers, and capping machines via sensors, ensuring timely, accurate placement in production flow.
3.Machine Traits
Processes up to 200 packages/minute for large-scale production.
PLC and servo-motor systems ensure minimal placement/dosing errors.
Intuitive touch-screen with multi-language support and real-time metrics.
GMP-compliant stainless steel construction for easy cleaning.
Adaptable to vials, bottles, and cartons with quick changeovers.
4.Logistics
Foam-wrapped in custom sturdy boxes with industrial sealing.
Global shipping via trusted couriers with tracking provided.
Includes manual and customs documentation support.
